| 規格 Specification | |
| 系統 System | |
| 處理器 Processor | Intel® 4th Gen. Core™ i3/i5/i7, Pentium®, Celeron® processor, LGA1150 Socket |
| 芯片 Chipset | Intel® H81 Chipset |
| 內存 Memory | DDR3-1333/1600MHz, 2 x UDIMM Slot, up to 16GB |
| 圖形 Graphics | Intel® HD Graphics, dual display |
| 存儲 Storage | 2 x SATA 2.0, 1 x SATA 3.0, 1 x M.2(2242/2280) |
| 操作系統 OS | Windows XP (limited function)/7/8/10, Linux |
| 外部接口 External I/O | |
| 網口 Ethernet | 2 x RJ45 Intel i211AT GbE (10/100/1000 Mbps) |
| 顯示 Video | 1 x VGA: max resolution up to 1920 x 1200 1 x DVI-D: max resolution up to 1920 x 1200 |
| 音頻 Audio | 1 x Line-in, 1 x Line-out, 1 x Mic-in |
| 串口 COM | 2 x RS232/RS422/RS485(with auto flow control,with Power 5V/12V) |
| USB | 6 x USB 2.0, 2 x USB 3.0(Support Ennoconn USB SR Pro Technology) |
| PS/2 | 1 x PS/2(mini-DIN-6) |
| 按鈕 Button | 1 x Power Button, 1 x Reset Button |
| 指示燈 LED | 1 x Power LED, 1 x HDD LED |
| 內部接口 Internal I/O | |
| 擴展接口 Expansion | 1 x PCIe X 16 Slot, 2 x PCIe X 4 Slot(X 1 Link), 4 x PCI Slot |
| USB | 2 x USB 2.0 (Type A + Pin header) |
| GPIO | 1 x 16-bit GPIO |
| 串口 COM | 2 x RS232/RS485, 2 x RS232 |
| 風扇 FAN | 1 x CPU Fan , 2 x System Fan |
| 環境 Environmental | |
| 操作溫度 Operating Temp. | 0℃ ~ 40℃ |
| 存儲溫度 Storage Temp. | -20℃ ~ 60℃ |
| 濕度 Relative Humidity | 5% ~ 95%, 非凝結狀態 Non-condensing |
| 隨機振動 Random Vibration | 5~500Hz, 1Grms (HDD)operation |
| 正弦振動 Sin Vibration | 5~500Hz, 2G Non-operation |
| 機械沖擊 Shock | 10G @ 11ms operation |
| 電源 Power | |
| 電源輸入 Power Input | 100~240V(AC) |
| 電源功耗 Power Watt | 250W |
| 機構Mechanical | |
| 外觀 Housing | SGCC |
| 尺寸 Dimension | 400(L) x 426.4(W) x 88.4(H)mm |
| 重量 Weight | 10kg(約) |
| 安裝方式 Mounting | 機柜式 (Rack-Mount) |
| 認證Certification | |
| 安規認證 Safety Certification | CCC |
